Description
WARN M8000 Winch with Synthetic Rope
M8000-s SPECS/PART NUMBERS Winch model: WARN M8000-s Part number: PN 88552
Rated line pull: 8,000 lbs., (3630 kg) single-line Motor: Series WoundElectrical controls: Contactor Remote Control: Remote switch 12′ (3.7m) lead Geartrain: 3-Stage Planetary Gear ratio: 216:1
Clutch (freespooling): Sliding Ring Gear Brake: Automatic Direct Drive Cone Drum diameter/Length: 2.5″/9.0″ (6.4cm/23cm)Weight: 55 lbs. (25 kg)Synthetic Rope: 80′, 3/8″ diameter (24.38m, 9.5mm diam.)
Fairlead: Polished Aluminum Hawse Recommended Battery: 650 CCA minimum for winching Battery leads: 2 gauge, 72″ (1.83m)
Finish: Argent Gray Powder Coat
