Description
• Rugged construction features drop-forged and heat treated pinion gear with totally enclosed mechanisms.
• Equipped with heavy-duty brake and high quality alloy steel chain for durable and safe operation.
• Free-chaining feature permits slack in the load chain to be taken up by hand before engaging the ratchet arm.
Capacity: 1500kg
Chain Falls: 1
Chain Length: 1.5m
Head Room: 295mm
Hook Aperture: 30mm
Lever Length: 410mm
Load Chain Diameter: Ø8mm
Maximum Hook Capacity Ø: 45mm
Nett Weight: 12kg
Operating Clearance: 104mm
Pull on Lever to Lift Full Load: 24kgf
Size (W x D): 160 x 172mm
Test Load: 2250kg
